USB Combo  Realtek WiFi BT Module RTL8822CU Dual Band 2T2R WiFi Bluetooth V5.0

USB Combo Realtek WiFi BT Module RTL8822CU Dual Band 2T2R WiFi Bluetooth V5.0

  • High Light

    wifi bluetooth module

    ,

    wifi bluetooth usb module

  • Description
    Support WiFi+Bluetooth
  • Product
    WiFi BT Module
  • WLAN
    802.11a/b/g/n/ac 2x2 MIMO
  • Bluetooth
    5.0 BR/EDR/LE
  • Platform
    Windows/Android /Linux
  • Manufacturer
    FN-LINK
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    CE/ROHS/REACH
  • Model Number
    6222D-UUC-W2
  • Minimum Order Quantity
    5/pcs
  • Price
    USD6.5-8.8/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

USB Combo Realtek WiFi BT Module RTL8822CU Dual Band 2T2R WiFi Bluetooth V5.0

Dual-Band WiFi BT Module RTL8822CU 2T2R WiFi + Bluetooth V5.0 USB Combo Module



This is a highly integrated Wireless Local Area Network (WLAN) system-on-chip (SOC) for 5GHZ 802.11ac, or 2.4/5GHz 802.11n WLAN applications. Dual-stream spatial multiplexing up to 867Mbps data rate is featured. It is based on the Realtek RTL8822CU chipset.



Features

1. Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ 802.11ac, or 2.4G/5G 802.11n WLAN applications.

2. Dual stream spatial multiplexing up to 867Mbps data rate

3. Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

4. Supports USB interface for WLAN and Bluetooth.

5. Complies with USB2.0 for WLAN and BT controller.

6. Supports Bluetooth V5.0+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

7. Support Bluetooth for class 1 and class 2 power level transmissions.

Specification

Part Number 6222D-UUC
General
Dimension
L x W x H: 27 x 18 x 2.03 mm
Interface Type USB 2.0 for WiFi and BT
Power Voltage 3.3V
Communication
Data Rate 867Mbps
Security WEP,TKIP,AES,WPA,WPA2
RF Specification
Operating Frequency
2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band)
4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band)
Antenna Reference
Small antennas with 0~2 dBi peak gain
Environment
Operating Temperature
0°C to 70°C
Humidity
Operating Humidity 10% to 95% Non-Condensing
Others
ROHS
All hardware components are fully compliant with EU
RoHS directive


Block Diagram

USB Combo  Realtek WiFi BT Module RTL8822CU Dual Band 2T2R WiFi Bluetooth V5.0 0

More Information
Welcome to visit our website or contact our sales to get the latest datasheet.
