M.2 Dual Band Wifi BT Module With PCM Interface Bluetooth Audio Module

Product Details

Place of Origin: China

Brand Name: OFLYCOMM

Certification: ROHS/REACH

Model Number: 8274C-PR

Payment & Shipping Terms

Minimum Order Quantity: 5/pcs

Price: USD 5.9-8/pcs

Packaging Details: Reel

Delivery Time: 15-40 workdays

Payment Terms: T/T

Supply Ability: 4000000pcs/month

Get Best Price
Highlight:

embedded wifi mod

,

wifi transceiver module

,

PCM Interface Wifi BT Module

Chipset:
QCA6174
Frequency:
2.4/5.8GHz
Size:
16.0 * 12.0 * 1.9mm
Data Rate:
867Mbps
Power Supply:
3.3.V
Type:
PCIE Wifi Module
Chipset:
QCA6174
Frequency:
2.4/5.8GHz
Size:
16.0 * 12.0 * 1.9mm
Data Rate:
867Mbps
Power Supply:
3.3.V
Type:
PCIE Wifi Module
M.2 Dual Band Wifi BT Module With PCM Interface Bluetooth Audio Module

M.2 Dual Band Wifi BT Module With PCM Interface Bluetooth Audio Module



Wifi BT Module Introduction

8274C-PR wifi bt module is a low-cost and low-power consumption module .The highly integrated module makes the possibilities of web browsing, VoIP, Bluetooth headsets applications.

8274C-PR wifi bt  module is based on Realtek qca6174 chip which supports 802.11a/b/b/n/ac.It is a dual band wifi modulle with dual external antenna.

Wifi BT Module Detailed Parameters

Model No 8274C-PR Main Chipset QCA6174
Interface PCIE WiFi Standard IEEE802.11a/b/g/n/ac
Data Rate 867Mbps Certification ROHS REACH
RF Antenna External Antenna OS Supported Android/Linux
Frequency 2.4/5.8GHz Power Supply 3.3V
Size 16.0*12.0*1.9mm RF Chain 2T2R
Operating Temperature -30° Cto 85°C Storage Temperature -40° Cto 125°C



Wifi BT Module Features

Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ.

802.11ac, or 2.4G/5G 802.11n WLAN applications.

Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

Supports low power SDIO3.0 interface for WLAN and UART/PCM interface for Bluetooth.

Supports Bluetooth V4.1+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

Supports Bluetooth for class1 and class2 power level transmissions without requiring an external PA.

BT host digital interface:
- HCI UART (up to 4 Mbps)
- PCM for audio data

Wifi BT Module Application Range

& Consumer Application

Tablet/Smart TV/IPTV/OTT/IPC/AI Speaker/Security System /Toys

& Commercial And OA Application

Printer/POS Terminal/Projector/Meeting System/Interactive WhiteBoard/Education Equipment

Note
Dear customer,please contact sales if you would like to know more details about this wifi bt module.
