Hi3861L Low Power Chip Wireless IP Camera SDIO WiFi Module

Hi3861L Low Power Chip Wireless IP Camera SDIO WiFi Module

  • High Light

    wifi bt combo module

    ,

    wifi low energy module

  • Product Introduction
    SDIO WiFi Module
  • Product Chipset
    Hi3861L
  • Frequency Range
    2.412~2.472GHz
  • Antenna Type
    1T1R External Antenna
  • Working Mode
    Ad-hoc/Infrastructure/Software AP/Wi-Fi Direct
  • Main Application
    Battery Smart Device
  • L X W X H
    12 X 12 X2.3 Mm
  • Product Feature
    Low Power
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    ROHS/REACH
  • Model Number
    3161A-SL
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 2-3/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

Hi3861L Low Power Chip Wireless IP Camera SDIO WiFi Module

Hi3861L Low Power Chip Wireless IP Camera SDIO WiFi Module



About 3161A-SL Low Power 2.4G SDIO WiFi Module
3161A-SL is a highly integrated 2.4 GHz Wi-Fi module that support the IEEE 802.11b/g/n baseband and RF circuit.
It is based on the latest Hisilicon Hi3681L chipset.
It supports 20 MHz standard bandwidth and 5 MHz/10 MHz narrow bandwidth, and provides a physical layer rate up to 72.2 Mbit/s.
Modulation

Orthogonal frequency division multiplexing -OFDM

Direct sequence spread spectrum-DSSS

Complementary code keying-CCK

Key Specifications

Operate at ISM frequency bands (2.4GHz)

Maximum rate of 72.2 Mbit/s@HT20 MCS7
SDIO interface for Wi-Fi
Low power dissipation
High transmitting power
High receiving sensitivity
PHY supporting IEEE 802.11b/g/n
MAC supporting IEEE802.11 d/e/h/i/k/v/w
Module integrated 32K clock
WFA WPA, WFA WPA2 personal, and WPS2.0 for Wi-Fi
Built-in 352 KB SRAM and 288 KB ROM
Main chipset Built-in 32bit MCU and 2 MB flash memory
Low Power Reference Design
