SDIO WiFi Module Hi3861L IC Chip For Low Power Wireless Data Transceiver

SDIO WiFi Module Hi3861L IC Chip For Low Power Wireless Data Transceiver

  • High Light

    wifi bt combo module

    ,

    wifi low energy module

  • Model Name
    3161A-SL
  • Product Description
    Support Wi-Fi Functionality
  • Ambient Temperature
    -40°C To 85°C
  • Operating Frequency
    2.412~2.472GHz
  • Media Access Control
    Wi-Fi: CSMA/CA With ACK
  • Antenna
    External Antenna
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    ROHS/REACH
  • Model Number
    3161A-SL
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 2-3/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

SDIO WiFi Module Hi3861L IC Chip For Low Power Wireless Data Transceiver

SDIO WiFi Module Hi3861L IC Chip For Low Power Wireless Data Transceiver

2021 Advanced Technology

1.orthogonal frequency division multiplexing -OFDM

2.direct sequence spread spectrum-DSSS

3.complementary code keying-CCK

Those three technology offers various data rates defined in the IEEE 802.11 b/g/n protocol.

Unique Bandwidth Of This SDIO Wifi Module

Standard bandwidth :It supports 20 MHz

Narrow bandwidth:5 MHz/10 MHz is supported

All About Main Chipset Hi3861L

Module chipset integrates a high-performance 32-bit microprocessor, a hardware security engine, and various peripheral interfaces, including the SPI, UART, I2C, PWM, GPIO, and multi-channel ADC. In addition, it provides high-speed SDIO2.0 slave interfaces, with clock frequency up to 50 MHz. Its built-in SRAM and flash can operate independently and even programming is allowed on the flash.

Special Diagram



SDIO WiFi Module Hi3861L IC Chip For Low Power Wireless Data Transceiver 0
