Product Details
Place of Origin: China
Brand Name: FN-LINK
Certification: ROHS/REACH
Model Number: F11AUUM23-W1
Payment & Shipping Terms
Minimum Order Quantity: 5/pcs
Price: USD4.9-6.5/pcs
Packaging Details: Reel
Delivery Time: 15-40 workdays
Payment Terms: T/T
Supply Ability: 4000000pcs/month
Date Code: |
New |
Module Name: |
Realtek WiFi Module |
Measure: |
23.0x17.0x3.0mm |
Line: |
Professional |
Packing: |
Tray/Reel |
MOQ: |
5 Pieces |
Date Code: |
New |
Module Name: |
Realtek WiFi Module |
Measure: |
23.0x17.0x3.0mm |
Line: |
Professional |
Packing: |
Tray/Reel |
MOQ: |
5 Pieces |
F11AUUM23-W1 is a 802.11a/b/g/n/ac USB Module which is based on Realtek RTL8811au chip with single external antenna.It compiles with ROHS,REACH Standard.
Wifi Standard
|
Features |
Descriptions |
|
|
Main Chipset |
Realtek RTL8811AU |
|
|
Operating Frequency |
2.4G: 2.4000GHz~2.4835GHz 5G: 5.150GHz~5.825GHz |
|
|
Host Interface |
USB 2.0 |
|
|
WIFI Standard |
iEEE802.11a/b/g/n/ac |
|
|
Modulation |
802.11b: QPSK , BPSK , 16QAM ,64QAM with OFDM |
|
|
PHY Data rates |
802.11a: 6,9,12,18,24,36,48,54Mbps 802.11b: 11,5.5,2,1 Mbps 802.11ac: up to 433.3Mbps |
|
|
Transmit Output Power |
802.11b@11Mbps 17±1.5dBm 802.11g@6Mbps 15±1.5dBm 802.11g@54Mbps 15±1.5dBm 802.11n@65Mbps 14±1.5dBm (MCS 0_HT20) 14±1.5dBm (MCS 7_HT20) 14±1.5dBm (MCS 0_HT40) 14±1.5dBm (MCS 7_HT40) 802.11a@54Mbps 13±1.5dBm 802.11ac@MCS7 13±1.5dBm 802.11ac@MCS9 13±1.5dBm |
|
Operation Range:Up to 150meters in open space
RF Antenna:External Antenna
OS Support:Windows XP,Vista.Win7
Operating Temperature: 0°C to +70°C
How to purchase
Please contact us before you order the samples that we can make sure this module can reach your requirement and keep your delivery time. The follow up support is based on the details of your project and exact problems during the testing.
