2.5GHz 150Mbps RTL8723DS Realtek WiFi Module For 2.4G Speaker

2.5GHz 150Mbps RTL8723DS Realtek WiFi Module For 2.4G Speaker

  • High Light

    150Mbps Realtek WiFi Module

    ,

    RTL8723DS Realtek WiFi Module

    ,

    2.5GHz WiFi Bluetooth Combo

  • Product Feature
    WiFi Bluetooth Combo
  • Product IC
    RTL8723DS
  • RF Specification
    802.11b/g/b+Bluetooth 4.2
  • Transmission Rate
    150Mbps
  • Network Architecture
    AD-HOC/Soft AP/STA/WiFi Direct
  • Operating Voltage
    3.3V
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    ROHS/REACH
  • Model Number
    6223B-SRD
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 2.1-3.8/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

2.5GHz 150Mbps RTL8723DS Realtek WiFi Module For 2.4G Speaker

RTL8723DS Realtek WiFi Module For 2.4G WiFi Bluetooth Speaker





Introduction

6223B-SRD is a low profile of Wi-Fi + BT Combo module with LGA (Land-Grid Array) footprint, board size is 15mm*13mm with module thickness of 1.5mm. It can be easily manufactured on SMT process and highly suitable for tablet PC, ultra book, mobile
device and consumer products. It provides SDIO interface for Wi-Fi to connect with host processor and high speed UART interface for BT. It also has a PCM interface for audio data transmission with direct link to external audio codec via BT controller. The Wi-Fi throughput can go up to 150Mbps in theory using 40MHz bandwidth and Bluetooth can support BT2.1+EDR/and BT4.2 systems.
2.5GHz 150Mbps RTL8723DS Realtek WiFi Module For 2.4G Speaker 0


General Specification



Controller Chip: Realtek RTL8723DS

Compatible with IEEE 802.11b/g/n standards

Operation at 2.4~2.5GHz frequency band to meet worldwide regulations

Fully qualified Bluetooth 4.2 + EDR specification including both 2Mbps and 3Mbps modulation mode

Supports WEP, WPA, WPA2

Driver support for Android, Linux, Windows



Block Diagram

2.5GHz 150Mbps RTL8723DS Realtek WiFi Module For 2.4G Speaker 1
