3.3V SDIO Wireless Transmitter Receiver Module Realtek RTL8821CS UART PCM

3.3V SDIO Wireless Transmitter Receiver Module Realtek RTL8821CS UART PCM

  • High Light

    3.3V SDIO Wireless Transmitter

    ,

    UART PCM SDIO Wireless Transmitter

    ,

    Realtek RTL8821CS Receiver Module

  • Chipset
    RTL8821CS
  • Frequency
    2.4GHz/5.8GHz
  • Size
    12.0x12.0x1.8mm
  • Data Rate
    433Mbps
  • Power Supply
    3.3V
  • Type
    5GHz WiFi Module
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    ROHS/REACH
  • Model Number
    6221A-SRC
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 4.2-6.8/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

3.3V SDIO Wireless Transmitter Receiver Module Realtek RTL8821CS UART PCM

Industrial SDIO Wireless Transmitter And Receiver Module Realtek RTL8821CS



5GHz WiFi Module Introduction

6221A-SRC 5ghz wifi module is based Realtek RTL8821CS chip which supports 802.11a/b/g/n/ac+BLE4.2. It is a 5ghz wifi module with single external antenna.It complies with IEEE 802.11 a/b/g/n/ac standard and it can achieve up to a speed of 433.3Mbps with single stream in 802.11ac draft to connect to the wireless LAN. The integrated module provides SDIO interface for Wi-Fi, UART / PCM interface for Bluetooth.





3.3V SDIO Wireless Transmitter Receiver Module Realtek RTL8821CS UART PCM 0



5GHz WiFi Module Detailed Parameters

Model No 6221A-SRC Main Chipset RTL8821CS
Interface SDIO/Uart WiFi Standard IEEE802.11a/b/g/n/ac
Data Rate 433Mbps Certification ROHS REACH
RF Antenna External Antenna OS Supported Windows/Linux/Android
Frequency 2.4GHz/5.8GHz Power Supply 3.3V
Size 12.0x12.0x1.8mm RF Chain 1T1R
Operating Temperature 0° C to 70°C Storage Temperature -40° C to 85°C





5GHz WiFi Module Features

Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ.

802.11ac, or 2.4G/5G 802.11n WLAN applications.

Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

Supports low power SDIO3.0 interface for WLAN and UART/PCM interface for Bluetooth.

Supports Bluetooth V4.1+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

Supports WLAN-Bluetooth coexistence and ISM-LTE coexistence.

Supports Bluetooth for class1 and class2 power level transmissions without requiring an external PA.

BT host digital interface:

- HCI UART (up to 4 Mbps)
- PCM for audio data



5GHz WiFi Module Application Range

& Consumer Application

Tablet/Smart TV/IPTV/OTT/IPC/AI Speaker/Security System /Toys

& Commercial And OA Application

Printer/POS Terminal/Projector/Meeting System/Interactive WhiteBoard/Education Equipment
