RTL8821CE WiFi Bluetooth Module BT Dual Mode Android Windows For Notebook

RTL8821CE WiFi Bluetooth Module BT Dual Mode Android Windows For Notebook

  • High Light

    data transmission module

    ,

    wifi transceiver module

  • WiFi Chipset
    RTL8821CE
  • Bluetooth Chipset
    Combo
  • Host Interface
    PCIe/USB/PCM
  • Linux
    Yes
  • Windows
    Yes
  • Android
    Yes
  • BT Dual Mode
    Yes
  • Line
    Professional
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    CE/FCC/ROHS/REACH
  • Model Number
    6221C-PUC
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 3.5-5.0/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

RTL8821CE WiFi Bluetooth Module BT Dual Mode Android Windows For Notebook

5GHz WiFi Module RTL8821CE WiFi And Bluetooth Module For Notebook



6221C-PUC offers a high bandwidth Wi-Fi/BLE transceiver solution for Linux & Android&Windows powered IoT systems, using the advanced 802.11ac technology.



Block Diagram

RTL8821CE WiFi Bluetooth Module BT Dual Mode Android Windows For Notebook 0

WiFi RF Specification

Feature
Description
WLAN Standard
IEEE 802.11b/g/n Wi-Fi compliant

          IEEE 802.11a/n/ac 2x2, Wi-Fi compliant

Frequency Range
2.400 GHz ~ 2.497 GHz (2.4 GHz ISM Band)

4.900 GHz ~ 5.845 GHz (5.0 GHz ISM Band)

Output Power
2.4G:
802.11b /11Mbps : 17 dBm ± 1.5 dB @ EVM ≤ -9dB
802.11g /54Mbps : 15 dBm ± 1.5 dB @ EVM -25dB
802.11n /MCS7 : 14 dBm ± 1.5 dB @ EVM -28dB
5G:
802.11a /54Mbps : 13 dBm ± 1.5 dB @ EVM -25dB
802.11n /MCS7 : 12 dBm ± 1.5 dB @ EVM -28dB
802.11ac /MCS9 : 11 dBm ± 1.5 dB @ EVM -32dB
Maximum Input Level
802.11b : -10 dBm
802.11g/n : -20 dBm
802.11a/n : -30 dBm
Antenna Reference
Small antennas with 0~2 dBi peak gain

Advantages

1. Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHz 802.11ac, or 2.4G/5G 802.11n WLAN

2. Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz

3. Supports low power PCI-e interface for WLAN and USB/PCM interface for Bluetooth

4. Supports Bluetooth V4.2+HS, BLE and be backwards compatible with Bluetooth 1.2, 2.X+ enhance data rate

5. Supports WLAN-Bluetooth coexistence and ISM-LTE coexistence

6. Supports Bluetooth for class1 and class2 power level transmissions without requiring an external PA

Enquire

Respect of the customer,please contact the sales staff before purchasing module to carry out pre-sale consultation.Otherwise,the module may not meet your needs or modules have no inventory.
Detailed specifications docs,please download from the official website or contact our sales.
