PCIe / Uart Wifi Bluetooth Usb Module QCA6174 Wifi Module For Pc

Product Details

Place of Origin: China

Brand Name: OFLYCOMM

Certification: CE/SRRC/ROHS/REACH

Model Number: 8274B-PR

Payment & Shipping Terms

Minimum Order Quantity: 5/pcs

Price: USD 5.9-8/pcs

Packaging Details: Reel

Delivery Time: 15-40 workdays

Payment Terms: T/T

Supply Ability: 4000000pcs/month

Get Best Price
Highlight:

qualcomm wifi module

,

wifi transceiver module

Chipset:
QCA6174
Frequency:
2.4GHz/5.8GHz
Size:
15.0x13.0x1.9mm
Data Rate:
867Mbps
Power Supply:
3.3V
Type:
5GHz WiFi Module
Chipset:
QCA6174
Frequency:
2.4GHz/5.8GHz
Size:
15.0x13.0x1.9mm
Data Rate:
867Mbps
Power Supply:
3.3V
Type:
5GHz WiFi Module
PCIe / Uart Wifi Bluetooth Usb Module QCA6174 Wifi Module For Pc

PCIe/Uart Interafce QCA6174 WiFi Bluetooth IC 5GHz WiFi Module For Mini PC



5GHz WiFi Module Introduction

8274B-PR 5ghz wifi module is based on Qualcomm QCA6174 chip which supports 802.11ac+Ble 4.2.It is a 5ghz wifi module with dual external antennas.



5GHz WiFi Module Detailed Parameters

Model No 8274B-PR Main Chipset QCA6174
Interface PCIe/Uart WiFi Standard IEEE802.11a/b/g/n/ac
Data Rate 867Mbps Certification ROHS REACH
RF Antenna External Antenna OS Supported Linux/Android
Frequency 2.4GHz/5.8GHz Power Supply 3.3V
Size 15.0x13.0x1.9mm RF Chain 2T2R
Operating Temperature -30° C to 85°C Storage Temperature -40° C to 125°C





5GHz WiFi Module Features

Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ.

802.11ac, or 2.4G/5G 802.11n WLAN applications.
Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

Supports low power PCI-e interface for WLAN and UART/PCM interface for Bluetooth.

Supports Bluetooth V4.2+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

Supports WLAN-Bluetooth coexistence and ISM-LTE coexistence.

Supports Bluetooth for class1 and class2 power level transmissions without requiring an external PA.

BT host digital interface:

- HCI UART (up to 4 Mbps)
- PCM for audio data



5GHz WiFi Module Application Range

& Consumer Application

Tablet/Smart TV/IPTV/OTT/IPC/AI Speaker/Security System /Toys

& Commercial And OA Application

Printer/POS Terminal/Projector/Meeting System/Interactive WhiteBoard/Education Equipment

Note
Welcome to visit our website to learn more about 5ghz wifi module.

PCIe / Uart Wifi Bluetooth Usb Module QCA6174 Wifi Module For Pc 0
