Android Tablet 5GHz Qualcomm Wifi Module QCA9377 802.11ac Wifi Module

Product Details

Place of Origin: China

Brand Name: QOGRISYS

Certification: CE/FCC/SRRC/IC/TELEC/ROHS/REACH

Model Number: 8223A-SR

Payment & Shipping Terms

Minimum Order Quantity: 5/pcs

Price: USD 4-6.8/pcs

Packaging Details: Reel

Delivery Time: 15-40 workdays

Payment Terms: T/T

Supply Ability: 4000000pcs/month

Get Best Price
Highlight:

PCM Wifi Bluetooth Module

,

SDIO Qualcomm Wifi Module

,

Android Tablet Qualcomm Wifi Module

Chipset:
QCA9377
WIFI Standard:
IEEE802.11a/b/g/n/ac
Interface:
SDIO/Uart/PCM
Size:
12.0x12.0x1.7mm
Antenna:
External Antenna
Type:
SDIO WiFi Module
Chipset:
QCA9377
WIFI Standard:
IEEE802.11a/b/g/n/ac
Interface:
SDIO/Uart/PCM
Size:
12.0x12.0x1.7mm
Antenna:
External Antenna
Type:
SDIO WiFi Module
Android Tablet 5GHz Qualcomm Wifi Module QCA9377 802.11ac Wifi Module

5GHz Qaulcomm QCA9377 802.11ac SDIO WiFi Module For Android Tablet



SDIO WiFi Module Introduction

8223A-SR sdio wifi module is a very high performance module that includes 2.4GHz/5GHz WLAN and Bluetooth functionality for consumer grade applications. Based on Qualcomm QCA9377, the module provides IEEE 802.11a/b/g/n/ac (1x1) and Bluetooth 4.2+EDR.

SDIO WiFi Module Detailed Parameters

Model No 8223A-SR Main Chipset QCA1023
Interface SDIO/Uart/PCM WiFi Standard IEEE802.11a/b/g/n/ac
Data Rate 433Mbps Certification ROHS REACH
RF Antenna External Antenna OS Supported Linux/Android/Windows
Frequency 2.4GHz/5.8GHz Power Supply 3.3V
Size 12.0x12.0x1.7mm RF Chain 1T1R
Operating Temperature -30° Cto 85°C Storage Temperature

-40° Cto 125°C



SDIO WiFi Module Features

Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ.

802.11ac, or 2.4G/5G 802.11n WLAN applications.

Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

Supports low power SDIO3.0 interface for WLAN and UART/PCM interface for Bluetooth.

Supports Bluetooth V4.1+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

Supports WLAN-Bluetooth coexistence and ISM-LTE coexistence.

Supports Bluetooth for class1 and class2 power level transmissions without requiring an external PA.

BT host digital interface:

- HCI UART (up to 4 Mbps)/ PCM for audio data

SDIO WiFi Module Application Range

OTT/IPTV/DVB/STB,Tablet PC,Laptop,Smart TV,IPC/NCR,Industrial Controllers ,DVR,Doorbell,Projector,AR/VR,Printer/POS Terminal,Electronic Scale,Drone,Robot,HDMI Transmitter,Smart Gateway,Education,Toys and other Consumer Electronics

Purchase

Please engage with our sales team to determine if this module is suitable for your applications.Regarding sample request,please inform us the detail of your project, thanks for your supports.

Android Tablet 5GHz Qualcomm Wifi Module QCA9377 802.11ac Wifi Module 0
