Product Details
Place of Origin: China
Brand Name: QOGRISYS
Certification: ROHS/REACH
Model Number: F23BUUD15-B1
Payment & Shipping Terms
Minimum Order Quantity: 5/pcs
Price: USD3.8-5.5/pcs
Packaging Details: Reel
Delivery Time: 15-40 workdays
Payment Terms: T/T
Supply Ability: 4000000pcs/month
Chipset: |
RTL8723BU |
WiFi Standard: |
IEEE802.11b/g/n |
Frequency: |
2.4Ghz |
Interface: |
USB |
OS Support: |
Android/Linux |
Security: |
WEP,TKIP,AES,WPA,WPA2 |
Size: |
61.2*19.2*8.0mm |
Application: |
TV BOX |
Chipset: |
RTL8723BU |
WiFi Standard: |
IEEE802.11b/g/n |
Frequency: |
2.4Ghz |
Interface: |
USB |
OS Support: |
Android/Linux |
Security: |
WEP,TKIP,AES,WPA,WPA2 |
Size: |
61.2*19.2*8.0mm |
Application: |
TV BOX |
F23BUUD15-B1 is a small size and low profile of WiFi/BT dongle, The size is 61.2mm*19.2mm*8.0mm. It can be highly suitable for tablet PC, ultra book, mobile device and consumer products. It provides USB interface for WiFi to connect with host processor and high speed USB interface for BT. The WiFi throughput can go up to 150Mbps in theory by using 1x1 802.11n b/g/n MIMO technology and Bluetooth can support BT2.1+EDR/BT3.0 and BT4.0.
F23BUUD15-B1 uses Realtek RTL8723BU, a highly integrated WiFi/BT single chip based on advanced COMS process. RTL8723BU integrates whole WiFi/BT function blocks into a chip, such as USB, MAC, BB, AFE, RFE, PA, EEPROM and LDO/SWR, except fewer passive components remained on PCB.
High Speed Wifi Dongle Detailed Parameters
| Model No | F23BUUD15-B1 | Main Chipset | RTL8723BU |
| Interface | USB | WiFi Standard | IEEE802.11b/g/n |
| Data Rate | 150Mbps | Certification | ROHS REACH |
| RF Antenna | Built-in Antenna | OS Supported | Linux/Android |
| Frequency | 2.4GHz | Power Supply | 5V |
| Size | 61.2*19.2*8.0mm | RF Chain | 1T1R |
| Operating Temperature | 0° C to 70°C | Storage Temperature | -40° C to 80°C |
High Speed Wifi Dongle Features
Operate at ISM frequency bands (2.4GHz)
USB for Wi-Fi and UBluetooth
IEEE standards support: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i
Fully Qualified for Bluetooth 2.1+EDR specification including both 2Mbps and 3Mbps modulation mode
Full–speed Bluetooth operation with Piconet and Scatternet support
Enterprise level security which can apply WPA/WPA2 certification for Wi-Fi.
Wi-Fi 1 transmitter and 1 receiver allow data rates supporting up to 150 Mbps downstream and 150 Mbps upstream PHY rates
& Consumer Application
Tablet/Smart TV/IPTV/OTT/IPC/AI Speaker/Security System /Toys
& Commercial And OA Application
Printer/POS Terminal/Projector/Meeting System/Interactive WhiteBoard/Education Equipment
& Industrial And Vehical Application
Instruments/Vehicle before-assembly/ afterassembly/High-speed train/Charging pile
& Medical Application
Medical equipments/Medical instruments
& Other Consumer Electronic Products
Note
Respect of the customer,please contact the sales staff before purchasing module to carry out pre-sale consultation.Otherwise,the module may not meet your needs or modules have no inventory.
Detailed specifications docs,please download from the official website or sales.
