RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode

RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode

Products - Dual Band Wifi Module
  • High Light

    wifi transmitter and receiver module

    ,

    wireless bluetooth module

  • Chipset Solution
    Realtek RTL8822BU
  • Spectral Band
    2.4/5GHz
  • Peak Speed
    867Mbps
  • Channel Utilization
    20/40/80MHz
  • MIMO Configuration
    2x2(2-stream)
  • Antenna Connector
    2 U.F.L
  • Place of Origin
    China
  • Brand Name
    FN-LINK
  • Certification
    FCC/ROHS/REACH
  • Model Number
    6222D-UUB-W2
  • Minimum Order Quantity
    5/pcs
  • Price
    USD 5.9-8/pcs
  • Packaging Details
    Reel
  • Delivery Time
    15-40 workdays
  • Payment Terms
    T/T
  • Supply Ability
    4000000pcs/month

RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode

  • RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode
  • RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode
  • RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode
  • RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode
  • RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode
Get Price Contact Now

RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode



Description

6222D-UUB is a IEEE802.11 a/b/g/n/ac, USB 2.0, Wi-Fi+Bluetooth 4.2 compliant module designed on a Realtek RTL8822BU chip. This chip is fully supported on the latest Kernel Linux versions. It  is thought to be used directly on a PCB instead of plugged in a USB port. It works at 3.3V  and can be configured in AP/STA/P2P mode.



Benefits

• Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ 802.11ac, or 2.4G/5G 802.11n WLAN applications.

• Dual stream spatial multiplexing up to 867Mbps data rate

• 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

• USB 2..0 for WLAN and Bluetooth.

• Bluetooth V4.2+HS, BLE and be backwards compatible with Bluetooth 1.2,2.X+ enhance data rate.

• Bluetooth for class 1 and class 2 power level transmissions.



Specification
Part No 6222D-UUB-W2
Product Function WiFi+Bluetooth
Wireless Standard IEEE802.11a/b/g/n/ac+Bluetooth 4.2
Dimension
L x W x H: 27 x 18 x 1.9 mm
Operating Temperature
0°C to 70°C
Operating Voltage 3.3V
Humidity
Operating Humidity 10% to 95% Non-Condensing
RoHS
 All hardware components are fully compliant with EU ROHS directive





Block Diagram

RTL8822BU Dual Band WiFi Module 5GHz Wireless WiFi Bridge Support AP/STA/P2P Mode 0
